उत्पाद का विवरण
उत्पत्ति के प्लेस: वानजाउ, चीन
ब्रांड नाम: Zheheng
प्रमाणन: ISO9001
मॉडल संख्या: टीपी317
दस्तावेज़: उत्पाद पुस्तिका पीडीएफ
भुगतान और शिपिंग शर्तें
Minimum Order Quantity: MOQ 1Ton
पैकेजिंग विवरण: जंगली मामलों या फूस में, या ग्राहकों की आवश्यकता के अनुसार
प्रसव के समय: भुगतान प्राप्त होने के 7-15 कार्य दिवस
भुगतान शर्तें: एल/सी, डी/पी, टी/टी, वेस्टर्न यूनियन
आपूर्ति की क्षमता: 1000 टन / टन प्रति माह
Thickness: |
1mm-150mm(SCH10-XXS) or as required |
OD: |
6mm-2500mm (3/8"-100") or as required |
खंड आकार: |
गोल, चौकोर, आयताकार |
Surface finish: |
Polishing, Hair line,Pickling |
मूल्य शर्तें: |
एफओबी, सीआईएफ, सीएफआर, EXW |
लंबाई: |
1000-12000 मिमी |
प्रयोग: |
औद्योगिक और वाणिज्यिक अनुप्रयोग |
तकनीक: |
कोल्ड ड्रॉ या हॉट रोल्ड |
इस्पात श्रेणी: |
200 सीरीज, 300 सीरीज, 400 सीरीज |
Thickness: |
1mm-150mm(SCH10-XXS) or as required |
OD: |
6mm-2500mm (3/8"-100") or as required |
खंड आकार: |
गोल, चौकोर, आयताकार |
Surface finish: |
Polishing, Hair line,Pickling |
मूल्य शर्तें: |
एफओबी, सीआईएफ, सीएफआर, EXW |
लंबाई: |
1000-12000 मिमी |
प्रयोग: |
औद्योगिक और वाणिज्यिक अनुप्रयोग |
तकनीक: |
कोल्ड ड्रॉ या हॉट रोल्ड |
इस्पात श्रेणी: |
200 सीरीज, 300 सीरीज, 400 सीरीज |
Trait
Good corrosion resistance: the main alloying elements of 317 stainless steel are chromium, nickel and molybdenum, which makes it have excellent corrosion resistance, especially suitable for strong acid, strong alkali and high temperature environment.
Excellent mechanical properties: 317 stainless steel has a high tensile strength and yield strength,elongation is also relatively high, but also has a high hardness and impact toughness, can still maintain stable performance in high temperature environment.
Easy to process and weld: 317 stainless steel can be processed and deformed by a variety of methods, such as cold working, hot working, deep drawing, etc.
High temperature strength: 317 stainless steel can still maintain high strength and stable performance in high temperature environment, which makes it widely used in high temperature field.
Specification
| Ends | Plain end |
| Production process |
The round steel→Peeling→Heating→Perforation→Acid picking→End preparation→Grinding→Lubricating→Cold-drawn→Degreasing→Annealing→Straightening→Acid picking→Finishing→Testing/inspection→seamless pipe→marking→packing→weighs→weighs→products storage→leaves the plant |
| Delivery time | within 45 -60 days. |
| Payment Terms | 40% prepayment Balance before lodaing. |
| Shipping Terms | FOB NINGBO, after the inspection of goods at supplier's warehouse |
| Package | Standard export seaworthy package,or as required. |
Architecture and Construction
Automotive and Transportation
Medical
Oil and Gas
Food and Drug
TP317 stainless pipe Chemical Composition
| Grade | C (Max) | Mn (Max) | P (Max) | S (Max) | Si (Max) | Cr | Ni | Mo | Nitrogen (Max) | Cu/ Others |
| TP317 | 0.08 | 2 | 0.045 | 0.03 | 0.75 | 18.00 - 20.00 | 11.00 - 14.00 | 3.00 - 4.00 | 0.1 | 0 |
Mechanical composition
| Grade | TensileStrength Mpa, (Min | Yield Strength Mpa, (Min) | %Age Elongation in 50mm gauge length min | Hardness (Max) | |
| BHN | Rb | ||||
| TP317 | 515 | 205 | 35 | 217 | 95 |
Physical Properties
| Thermal Conductivity | 14.6 | W.m -1.°K-1 |
| Density | 7.99 | g/cm3 |
| Specific Heat (0 To 100°C) | 500 | J.kg-1.°K-1 |
| Thermal Expansion | 16.5 | mm/m/°C |
| Modulus Elasticity | 193 | GPa |
| Electrical Resistivity | 7.4 | μohm/cm |
Uses
Offshore oil rigs
Chemical storage tanks
Fuel injection systems
Aerospace components
Kitchen appliances,architectural cladding panels and automobile exhaust systems
Product Testing
Coating Thk Test
Geometry inspection
Ultrasonic Inspection
Nondestructive Testing
Hydrostatic Testing
Package Process
1.with plastic cap to protect both ends
2.weaving bag wrapped outside the pipe
3.then pack into wooden case.
