उत्पाद का विवरण
उत्पत्ति के प्लेस: वानजाउ, चीन
ब्रांड नाम: Zheheng
प्रमाणन: ISO9001,ISO14001, TS16949
Model Number: DIN 1.4306
दस्तावेज़: उत्पाद पुस्तिका पीडीएफ
भुगतान और शिपिंग शर्तें
Minimum Order Quantity: MOQ 1Ton
पैकेजिंग विवरण: जंगली मामलों या फूस में, या ग्राहकों की आवश्यकता के अनुसार
प्रसव के समय: भुगतान प्राप्त होने के 7-15 कार्य दिवस
भुगतान शर्तें: एल/सी, डी/पी, टी/टी, वेस्टर्न यूनियन
आपूर्ति की क्षमता: 1000 टन / टन प्रति माह
Thickness: |
1mm-150mm(SCH10-XXS) or as required |
OD: |
1/8''-80 |
खंड आकार: |
गोल, चौकोर, आयताकार |
Surface finish: |
Polishing, Hair line,Pickling |
मूल्य शर्तें: |
एफओबी, सीआईएफ, सीएफआर, EXW |
लंबाई: |
1000-12000 मिमी |
Application Fields: |
Marine,Construction Industry |
तकनीक: |
कोल्ड ड्रॉ या हॉट रोल्ड |
Thickness: |
1mm-150mm(SCH10-XXS) or as required |
OD: |
1/8''-80 |
खंड आकार: |
गोल, चौकोर, आयताकार |
Surface finish: |
Polishing, Hair line,Pickling |
मूल्य शर्तें: |
एफओबी, सीआईएफ, सीएफआर, EXW |
लंबाई: |
1000-12000 मिमी |
Application Fields: |
Marine,Construction Industry |
तकनीक: |
कोल्ड ड्रॉ या हॉट रोल्ड |
Characteristic
DIN1.4306 belong to low carbon steel grade,Rather than its demonstrates excellent corrosion resistance.For severely corrosive environments, the lower content of Type SUS304L is preferred because of its greater immunity to intergranular corrosion.DIN 1.4306 stainless steel include in the Power Genration Industry ,Chemical Industry ,Oil&Gas Industry, Petrochemical Industry.
Specification
| Ends | Plain end |
| Standard | EN |
| Delivery time | within 45 -60 days. |
| Payment Terms | 40% prepayment Balance before lodaing. |
| Shipping Terms | FOB NINGBO, after the inspection of goods at supplier's warehouse |
| Package | Standard export seaworthy package,or as required. |
| Grade | C ≤ | Si ≤ | Mn ≤ | P ≤ | S ≤ | Ni ≤ | Cr ≤ | N≤ |
| DIN1.4306 | 0.030 | 1.00 | 0.80 | 0.040 | 0.015 | 10.00-12.00 | 18.00-19.00 | 0.11 |
Mechanical propertoes
| Material | Tensile strength(Mpa) | Yield point(Mpa) | Elongation(%)Longitudinal | Elongation(%)transverse |
| 1.4306 | 480-680 | 180 | 40 | 35 |
Product Testing
Coating Thk Test
Geometry inspection
Ultrasonic Inspection
Nondestructive Testing
Hydrostatic Testing
Package Process
1.with plastic cap to protect both ends
2.weaving bag wrapped outside the pipe
3.then pack into wooden case.
