उत्पाद का विवरण
उत्पत्ति के प्लेस: वानजाउ, चीन
ब्रांड नाम: Zheheng
प्रमाणन: ISO9001
Model Number: EN 1.4571
Document: उत्पाद पुस्तिका पीडीएफ
भुगतान और शिपिंग की शर्तें
Minimum Order Quantity: MOQ 1Ton
पैकेजिंग विवरण: जंगली मामलों या फूस में, या ग्राहकों की आवश्यकता के अनुसार
प्रसव के समय: भुगतान प्राप्त होने के 7-15 कार्य दिवस
भुगतान शर्तें: एल/सी, डी/पी, टी/टी, वेस्टर्न यूनियन
आपूर्ति की क्षमता: 1000 टन / टन प्रति माह
Thickness: |
1mm-150mm(SCH10-XXS) or as required |
OD: |
6mm-2500mm (3/8"-100") or as required |
खंड आकार: |
गोल, चौकोर, आयताकार |
Surface finish: |
Polishing, Hair line,Pickling |
मूल्य शर्तें: |
एफओबी, सीआईएफ, सीएफआर, EXW |
लंबाई: |
1000-12000 मिमी |
प्रयोग: |
उद्योग |
तकनीक: |
कोल्ड ड्रॉ या हॉट रोल्ड |
इस्पात श्रेणी: |
200 सीरीज, 300 सीरीज, 400 सीरीज |
Thickness: |
1mm-150mm(SCH10-XXS) or as required |
OD: |
6mm-2500mm (3/8"-100") or as required |
खंड आकार: |
गोल, चौकोर, आयताकार |
Surface finish: |
Polishing, Hair line,Pickling |
मूल्य शर्तें: |
एफओबी, सीआईएफ, सीएफआर, EXW |
लंबाई: |
1000-12000 मिमी |
प्रयोग: |
उद्योग |
तकनीक: |
कोल्ड ड्रॉ या हॉट रोल्ड |
इस्पात श्रेणी: |
200 सीरीज, 300 सीरीज, 400 सीरीज |
Characteristic
EN 1.4571 by adding titanium (Ti) to improve the resistance to intergranular corrosion. Titanium can improve the corrosion resistance of stainless steel, especially intergranular corrosion, effectively prevent the sensitization of stainless steel, and also improve the stability of steel in high temperature and high pressure. When the mass fraction of titanium is between 0.03% and 0.1%, the yield strength of the steel is improved. Therefore, EN 1.4571 material has higher temperature resistance, corrosion resistance and sensitization resistance.
Specification
| Ends | Plain end |
| Production process |
The round steel→Peeling→Heating→Perforation→Acid picking→End preparation→Grinding→Lubricating→Cold-drawn→Degreasing→Annealing→Straightening→Acid picking→Finishing→Testing/inspection→seamless pipe→marking→packing→weighs→weighs→products storage→leaves the plant |
| Delivery time | within 45 -60 days. |
| Payment Terms | 40% prepayment Balance before lodaing. |
| Shipping Terms | FOB NINGBO, after the inspection of goods at supplier's warehouse |
| Package | Standard export seaworthy package,or as required. |
Architecture and Construction
Automotive and Transportation
Medical
Oil and GasFood and Drug
1.4571 stainless pipe Chemical Composition
| C | Si | Mn | P | S | Cr | Ni | Mo | Ti |
| 0.08 | 1.00 | 2.00 | 0.045 | 0.015 | 16.5 | 10.5-13.0 | 2.00-2.50 | 5xC-0.70 |
Product Testing
Coating Thk Test
Geometry inspection
Ultrasonic Inspection
Nondestructive Testing
Hydrostatic Testing
Package Process
1.with plastic cap to protect both ends
2.weaving bag wrapped outside the pipe
3.then pack into wooden case.
